The LTE Dash Cam VT01 is a cost-effective 4G dash cam equipped with a 4G Cat.1 module for communication and can fix positions via the Global Positioning System (GPS) and the BeiDou Navigation Satellite System (BDS). With the built-in high-definition camera, the VT01 can capture and upload clear important videos and send out alerts to notify back-office managers when a vehicle has been involved in an accident or encountered other emergencies, so drivers will receive faster help, and vehicles and assets will be protected from further damage.
Live APP Monitoring
Live Web Monitoring
LTE Dash Cam VT01 Features:
1 GPS Location Tracking
Live location and vehicle status tracking and monitoring by Web and APP.
2 Live video monitoring and recording
Monitor videos real-time from phone based APP and Web tracking system
3 Single Camera
Forward face camera for live video monitoring
4 Monitoring center:
Centralized facility or location where data from various telematics devices is collected, processed, and monitored in real-time. The center serves as a command hub where trained personnel can observe and analyze data
5 ON/OFF board storage with SD Card
Remote storage for video telematics data. Local storage for video telematics data
6 Built-in G sensor.
The system has a G-sensor that detects events such as acceleration, deceleration and impacts and incase of abnormal occurrence, it shall trigger alerts to the driver.
7 Event-based reports.
The system has capability to transmit event-based data and real-time data to the designated server.
8 Power supply
The system functions normally when connected to a power supply in the range of 10V~36V and consume a maximum power of 12 W. The system has an in-built battery capable of sustaining the system for a minimum of 30 min. To ensure continued recording during power interruptions.
9 SOS alarm:
SOS button to call preset phone numbers in case of emergency.
10 SD card compatibility.
Insert SD card to store recorded videos locally.
11 Engine status detection
Engine detection wire is connected to vehicle ACC wire so as to detect vehcle engine status
12 Backup battery
Built in backup battery to work even when vehicle ACC engine is off, so as to record alarms triggered by vibration and collision.
13 Two way voice speaking
Built-in speaker and microphone can start two way voice speaking once admin number is set.
VT01 4G LTE Car Camera Specifications:
| Items | Specifications |
| Model | VT01 LTE Dash Cam |
| Dimension | L99mm*W52mm*H41mm |
| Weight | 102g |
| GNSSS | |
| Positioning mode | GPS,GLONASS,CALILEO,BEIDOU,AGPS |
| Antenna | Internal High Gain antenna |
| Receiver | 64 channel |
| Tracking Sensitivity | -160 dB |
| Position Accuracy | <2.0 m CEP |
| Velocity Accuracy | <0.1 m/s |
| Hot Start | <1 s |
| Warm Start | <4 s |
| Cold Start | <28 s |
| Cellular | |
| Frequency | LTE-FDD: B1/B2/B3/B4/B5/B7/B8/B20/B28/B66 LTE-TDD: B34/B38/B39/B40/B41 |
| Antenna | Internal 4G/GSM High Gain Antenna |
| Data transfer | LTE:Max10Mbps(DL)/Max5M bps(UL) GSM:Max85.6Kbps(DL)/Max85.6Kbps(UL) |
| Power | |
| Working Voltage | 9V-90V |
| Power Consumption | At 12V<6mA (Online Sleep)
At 12V<180mA (Normal) |
| Operating Environment | |
| Operating Temperature | -20 °C to +75 °C |
| Storage Temperature | -40 °C to +85 °C |
| Operating Humidity | 5% to 95% non-condensing |
| Ingress Protection Rating | IP50 |
| Interface | |
| Digital input | 1 |
| LED Indication | 3 status LED lights |
| SIM | Micro-SIM |
| Button | Reset button |
| Video Parts | |
| System Structure | Linux |
| Chip | SSC333E |
| Resolution | 2.0 MP |
| Sensor Resolution | 1920*1080 |
| Lens | 3.6MM |
| View Angle | 96° |
| Pan-til | Vertical: 50° |
| Video compression Standard | H.265(default)/H.264 |
| Video Format | MP4 |
| Electronic Shutter | Auto |
| Backlight compensation | Support |
| Audio In | MIC |
| Audio Out | Speaker |
| Storage | TF Card Max 128G |
| Application | Suitable for auto finance, leasing, mortgage, and other fleet management |
VT01 4G dash cam is set to work with GPS51 GPS Tracking platform and tracking APP. Steps to make the car camer work:
1 Park vehicle at an open place
2 Insert a compatabile 4G SIM Card. Make sure it has data plan and support voice calling and SMS functions.
3 Insert a TF card if there is need of local video storage
4 Connect power to the dash camera and also connect ACC detection wire
5 Login your account at GPS51 and start to monitor.
