4G magnet GPS Tracker GL700 is a newly designed location tracker with 4G bands. Due to the fact that 2G networks in all countries have a sunset date. The market for 2G is becoming few and we are determined to develop mode 4G module-based GPS tracking devices.
GL700 4G magnet GPS tracker comes with 10,000 rechargeable battery. It has 3 working modes:
Fixed tracking mode: 4G GPS reports to the server at a preset interval, which consumes power fastest.
Smart tracking mode: 4G magnet tracker shall go to sleep mode if there is no shock or movement. It wakes up and starts to report location data to the server when there is shock and movement.
Power saving mode: 4G tracker goes to sleep mode at most times and sends data to the server at the preset long interval. It appears offline on web tracking software.
GL700 uses SIMCOM76770SA chipset so it works with 4G bands in most countries Its supporting bands are as below:
LTE FDD: B1/B2/B3/B4/B5/B7/B8/B28/B66
2G: 850/900/1800/1900Mhz
GL700 also has a built-in MIC for remote voice monitoring (voice monitoring is removed due to law requirement in China), at most 3 numbers can be set to listen in voice around. With a light sensor, an instant alarm shall be sent if the device is removed from its current location.
GL700 4G Magnet GPS Tracker Specifications:
Items |
Specifications |
Model |
GL700 |
Internet |
LTE 4G + 2G GSM |
GSM Chip |
SIMCOM7670SA |
Bands |
4G B1/B2/B3/B4/B5/B7/B8/B28/B66 2G GSM/GPRS/EDGE: 850/900/1800/1900MHz |
Internet speed |
GPRS:Max 85.6Kbps(DL) / Max 85.6Kbps(UL) FDD-LTE:non-CA Cat1,Max 10Mbps(DL)/Max 5Mbps(UL) TDD-LTE:non-CA Cat1,Max 8Mbps(DL)/Max 2Mbps(UL) |
GNSS details |
GPS and BeiDou and GLONASS GPS location accuracy: 5m outdoor Speed accuracy: 0.1m/s Cool start: -148dbm Tracking sensitivity: -162dbm |
Location Method |
GPS+LBS+WIFI+BeiDou |
GNSS antenna |
25*25*2 mm |
Switch |
On/Off |
MIC |
NO |
Light sensor |
For removal alarm |
3D G-sensor |
Support. For power saving control |
Installation |
Magnet |
SIM card |
Micro-SIM |
Light |
GSM and GPS signal, as well flashing for finding device. |
Charging |
Type-C USB charging |
Battery |
Built-in rechargeable 10000 mAh |
Working current |
GPS ON: 4V/ 35 mA in average GPS OFF: 4V/ < 5 mAh in average |
AGPS |
Support |
Size |
101*67*25 mm |
Weight |
303g |
Working temperature |
-30 to 75 °C |
Storage temperature |
-40 to 90 °C |
